Specifications
| General | |
|---|---|
| Frequency coverage Rx Tx |
0.030– 60.000 MHz*1 1.800–1.999, 3.500–3.999, 5.255–5.405*2 7.000–7.300, 10.100–10.150, 14.000–14.350, 18.068–18.168, 21.000–21.450, 24.890–24.990, 28.000–29.700, 50.000–54.000 MHz *1 Guaranteed range: 0.500–29.999, 50.000–54.000 MHz. *2 Some frequency bands are not guaranteed. |
| Mode | USB, LSB, CW, RTTY, PSK31/63, AM, FM |
| Number of channels | 101 (99 regular, 2 scan edges) |
| Antenna connectors | SO-239 × 2 (50 Ω unbalanced (Tuner off)) BNC × 1 (RX antenna In/Out) |
| Power supply requirement | 13.8 V DC ±15% |
| Operating temperature range | 0°C to +50°C; +32°F to +122°F |
| Frequency stability | Less than ±0.5ppm (0°C to +50°C, after warm up) |
| Frequency resolution | 1 Hz (minimum) |
| Power consumption TX RX |
23 A (at 100 W output power) 3.0 A (Standby), 3.5 A (Maximum audio) |
| Dimensions (W×H×D) (projections not included) |
340 × 118 × 277 mm; 13.4 × 4.6 × 10.9 in |
| Weight (approx.) | 8.5 kg; 18.7 lb |
| Transmitter | |
|---|---|
| Output power (HF/50 MHz) | SSB/CW/FM/RTTY/PSK: 1–100 W AM: 1–25 W Digital P.S.N. |
| Modulation system SSB AM FM |
Digital P.S.N. modulation Digital low power modulation Digital Reactance modulation |
| Spurious emission HF Bands 50 MHz band |
Less than –50 dB Less than –63 dB |
| Carrier suppression | More than 50 dB |
| Unwanted sideband | More than 50 dB |
| Microphone impedance | 600Ω (8-pin connector) |
| Receiver | |
|---|---|
| Receiver system | Direct Sampling Superheterodyne |
| Intermediate frequencies | 12 kHz |
| Sensitivity*3 SSB/CW (at 10 dB S/N) AM (at 10 dB S/N) FM (at 12 dB SINAD) |
0.5– 1.799 MHz
– 6.3 μV typ. – 1.8– 29.999 MHz
0.16 μV typ. 2.0 μV typ. – 28.0– 29.7 MHz
– – 0.5 μV typ. 50–54 MHz
0.13 μV typ. 1.0 μV typ. 0.32 μV typ. *3 HF: Preamp 1 ON, 50 MHz: Preamp 2 ON, BW: SSB/CW=2.4 kHz, AM=6 kHz, FM=15 kHz
|
| Squelch sensitivity (Threshold) | SSB: Less than 3.2 μV (Preamp ON) FM: Less than 0.32 μV (Preamp ON |
| Selectivity (Filter shape: Sharp) SSB (BW: 2.4 kHz) CW (BW: 500 Hz) RTTY (BW: 500 Hz) AM (BW: 6 kHz) FM (BW: 15 kHz) |
More than
2.4 kHz/–6 dB 500 Hz/–6 dB 500 Hz/–6 dB 6.0 kHz/–6 dB 12.0 kHz/–6 dB Less than
3.6 kHz/–60 dB 700 Hz/–60 dB 700 Hz/–60 dB 15 kHz/–60 dB 20 kHz/–60 dB |
| Spurious and image rejection ratio HF bands 50 MHz band |
More than 70dB More than 70 dB (Except for ADC Aliasing) |
| Audio output power | More than 2.6W at 10% distortion with an 8Ω load |
| Tuner | |
|---|---|
| Frequency range | 1.9–50 MHz bands |
| Matching impedance range | 16.7 Ω–150 Ω unbalanced (VSWR better than 3: 1) |
| Tuning accuracy | VSWR 1.5: 1 or less |
| Tuning time | 2–3 seconds (average) (Maximum 15 seconds) |
All stated specifications are subject to change without notice or obligation.
Supplied Accessories
- Hand microphone, HM-219
- DC power cable
- Fuses
- Plugs
