Sirio Signal Keeper 1/4 Base Antenna CB

Μια κλασική 1/4 λ κεραία CB βάσης ύψους 2370 mm, διακριτική και ιδανική αν δεν έχετε πολύ χώρο στην ταράτσα σας.

Η κεραία μπορεί να τοποθετηθεί σε μια γωνία ή στο μπαλκόνι.

Features:

–              Base station antenna

–              Omnidirectional, Compact dimensions

–              Factory tuned at mid-band

–              Made of aluminium alloy 6063 T-832

–              Side mast mounting allowed by optional bracket FT-2

Electrical Data

–              Type: 1/4 λ base loaded ground plane

–              Frequency range: 26-28 MHz

–              Impedance: 50Ω

–              Radiation (H-plane): 360° omnidirectional

–              Polarization: linear vertical

–              Gain: 0 dBd, 2.15 dBi

–              Bandwidth @ SWR ≤ 2: ≥ 850 KHz

–              SWR @ res. freq.: ≤ 1.2

–              Max. power:

100 Watts (CW) continuous

300 Watts (CW) short time

–              Feed system / position: Direct / Center

–              Connector: UHF-female

Mechanical Data

–              Materials: Aluminium, Steel, Nylon

–              Wind load / resistance: 36 N at 150 Km/h / 130 Km/h

–              Wind surface: 0.03 m²

–              Height (approx.): 2370 mm

–              Weight (approx.): 640 gr

–              Radial length (approx.): 640 mm

–              Mounting mast: Ø 35-40 mm
