FEATURES:
- Frequency range: 1.6-60MHz
- Measurement (analog mode): CW, FM, FDMA
- Measurement (MAX mode): AM, SSB
- Calibration point: 14/50 MHz
- Power range: 1: 300mW – 300W; 2: 300W – 1200W
- Input/output connector: SO239
- Error margin: 1.6-30MHz: +/- 5%
- Minimum power for SWR: 300mW
- Insertion loss: Less than 0.1 dB
- Input/output impedance: 50 ohms
- Dimension (W/H/D): 140 x 84 x 122mm.
- Weight (net): 750 g.
INCLUDES:
- Nissei DG-503 MAX Meter
- Manual
- 12 Vdc cable.
