RG213BX ΟΜΟΑΞΟΝΙΚΟ 50 OHM (KPO-RG213)

Τιμη ανα μετρο
Our RG 213 cable is CPR (Construction Products Regulation) compliant and have the ECA classification. More information about CPR you can find here:

https://ec.europa.eu/growth/sectors/construction/product-regulation_en

• Plain copper inner conductor: CU 7 x 0,75 mm
• Low density polyethylene dielectric: PE ø 6,50 ± 0,15 mm
• Plain copper outer conductor CU 168 x 0,15 mm
• Percentage coverage 91%
• Non-contaminating polyvinyl-chloride sheath PVC2 ø 9,50 ± 0,18 mm
• Sheath’s colour : BLACK
• Copper weight 59,6 Kg/Km
• Cable weight 135,1 Kg/Km
• Impedance: 50 ± 3 Ohm
• Capacitance 100 pF/m
• Velocity ratio: 66%
• Inner conductor resistance 6 Ohm/Km
• Outer conductor resistance 7 Ohm/Km
• Temperature range -30 °C / +70 °C
